Explosion Proof Pressure Sensor

Products Description   The intrinsically safe P20EX pressure transmitter, designed for hazardous environments, ensures reliable pressure measurement in demanding applications. Certified Ex ia IIC T6, it offers a 4-20 mA output, absolute and gauge versions, and diverse pressure ranges. Featuring excellent vibration stability, robust construction, high EMC/EMI protection, and elevated operating temperature, this transmitter meets stringent industrial standards. Find flexibility in plug connections and a wide array of pressure connections for diverse applications in challenging conditions.   Product Features   High accuracy ≤±0.5%F.S. and long-term stability 0.1%F.S, ensuring reliable pressure measurements in demanding environments. Industrial silicon sensor adopted for enhanced stability and reliability. Digital calibration system for precise and efficient calibration. Multifarious electronic connectors and pressure ports for flexible application.   Product Specification   Pressure Range -1 Bar-0-1 Bar; 0-0.1Bar…..600 Bar / 0-1 Psi…9000 Psi Optional Pressure Type: Gauge pressure; Absolute pressure optional. Safe Overload 150% F.S.(standard) Burst Pressure 300% F.S. (standard) Accuracy: (Linearity Hysteresis Repeatability) ≤ ±0.5%F.S ≤ ±0.25%F.S customized Including non-lin., rep. and hys. Optional Long-term Stability Standard: 0.1%F.S±0.05% Working/Storage Temp. -30℃~85℃ Tempe Compensation -10℃~60℃ Medium compatible Compatible with 316 Stainless Steel Electrical Wire 2 Wires Output 4~20mA Power Supply 12~30 V DC Body materials 304/316 stainless steel (standard); 1Cr18Ni9Ti stainless steel optional Material of diaphragm 316L Stainless steel Filling oil Silicon oil (standard); Fluorocarbon oil (Oxygen Services) Electrical connection 1/2”NPT male thread with outlet cable IP68 Pressure connect port G1/4”male, G1/2”male, 1/4”NPT male, 1/2”NPT male and female optional. Water Proof IP68   Product Dimensions
